A Review on the Occipital Area Morphology in Nyctereutes Procyonoides cancrivora--Evidence for Developmental Instability?

Samuel O.M1,2 , Olopade J.O1
1 Department of Veterinary Anatomy University of Ibadan, Nigeria
2 Department of Veterinary Anatomy University of Agriculture Makurdi, Nigeria
Author    Correspondence author
Animal Molecular Breeding, 2016, Vol. 6, No. 2   doi: 10.5376/amb.2016.06.0002
Received: 22 Jan., 2016    Accepted: 01 Feb., 2016    Published: 22 Apr., 2016
© 2016 BioPublisher Publishing Platform
This is an open access article published under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
Preferred citation for this article:

Samuel O.M. and Olopade J.O., 2016, A Review on The Occipital Area Morphology in Nyctereutes Procyonoides cancrivora)–Evidence For Developmental Instability?, Animal molecular Breeding, 6(2): 1-6 (doi: 10.5376/amb.2016.06.0002)


The occipital bone and the foramen magnum are salient structures of the skull; which have been widely studied in various species due to variability associated with their morphology and the clinico-paleontological significance of related ‘anomalies’. The aim of this study was to discuss and review literatures on the development, form and construction of the structures in tropical raccoon dogs (Nyctereutes procyonoides cancrivora) a species noted as most variably sized. Relevant aspects of predisposition to and diagnosis of neuro-pathologies related to the occipital area as well as species variations in composite architecture of the bone and foramen magnum in evolutionary perspectives. This review postulates elements of developmental instability exist with predisposition to dysmorphologies in the occipital area of this species and suggests that this investigation may be of value in canalization, ontogenetic variability and population studies and serve as important research data in cranio-facial modeling for species anthropometry and taxonomic classifications.


Developmental Anatomy; developmental instability; Occipital bone; embryology; morphology; N.p. cancrivora

1 Introduction

1.1 The occipitum

The evolving biology of skull development in relation to ancestry does constrain the morphotype changes possible in the occipital bone (Gilbert, 2006) with genetic variants disposition to more or less mutation- thresholds through modularity (Conlon and Raff, 1999), and may induce various changes through correlated progression on the foramen magnum (Gilbert, 2006), the ratio of which size increases with skull index though not with shape (Ellis et al., 2009). Radiations and reintroduction of raccoons into new lands has been observed to impact skull size and shape negatively compared to fossil forms (Nowak, 1984; Nowicki et al., 2011). The squama occipitalis morphology in raccoon dogs has been reported to be trapezoid (Hidaka et al., 1997; Hatori et al., 2003) in Japanese raccoon dogs (Nyctereutes .procyonoides.Viverrinus) but more triangular in the species found around Finland (N.pUssuriensis) and Korea (Nyctereutes procyonoides Koreensis) (Kauhala et al., 1998), similar to those found in tropical environments (N.p cancrivorus). Buffering effects of developmental constraints on evolution of new phenotypes such as canalization may be overcome by stress factors in different environment (Halgrimson et al., 2004).


A dorsal median symmetrical division of the bone by a prominent crista occipitalis externa (Jurgelenas et al., 2007) forms the median demarcation of two lateral depressions. Epigenetic incident frequencies have been reported to be increased (Samuel et al., 2015)* independent of sex and side, the canalis condylaris varies in number and location between and within species. There is no consensus among several authors on the construction of this bone; little information exists on excavations and numerous foramina perforating the external aspect of this structure, along with bilateral grooves which indents the cerebral surface. The occipital sensory area of the brain resides in the saucer-like bone (Figuti, 2004). The Pars basilaris maintains a constant morphology among the subspecies (Hatori, 1997; Hidaka, 2003).


1.2 Anatomical and paleontological implications

Chromosomal similarities and differences among populations have been reported earlier (Nyctereutes procyonoides and Nyctereutes procyonoides Ussuriensis possess 54 chromosomes while N.p. Viverinnus possess 38) (Makinen et al., 1986; Ward et al., 1987), ten homologous autosomes have been recognized while the remaining chromosomes arms are homologous due to reduction in chromosomal number in Japanese raccoons via Robertsonian translocations; an occurrence known only in new species evolution (Mayr, 1976).


1.3 The foramen magnum and the contributions of allometry

Size, shape and architecture of the foramen magnum differ among species, gender and individuals (De La-hunta, 1983; Rholf, 2010). Foramen magnum index among the subspecies peaks within juveniles’ age group especially in the smaller subspecies (Zevellof, 2002) though foramen margin morphology remains poorly described, the occurrence of dorsal notches has not been properly documented in this subject as morphologic variants of supra-occipital bone ossification differences and not necessarily pathologic (Janeczek et al., 2008; Watson et al., 1989) and compatible with longevity more so, they are not associated with any other skull bone deformities except a degree of directional asymmetry observed in the construction giving rise to behavioral trait (handedness) in adults (Samuel et al., 2015)*. The most caudo-ventral portion morphology of the occipital condyles also offers variations which may be of further relevance in classification of the family.


1.4 Anatomical and clinical significance

Occipital index in adulthood in the subspecies of this family differs both from ecologic and subspecies point of view (Ewer, 1985; Baltrunaite, 2005; Gibson, 2000; Rusbridge and Knowler, 2006; Reid and Helgen, 2008). Females, in this regard has about 15% attenuated size development of the skull bones (IUCN, 2012). As in other canids, the possibility of cerebellar protrusion occasioned by volume reduction of the posterior fossa, syringomyelia and neurological disorders (Rusbridge and Knowler, 2006; Simoens et al., 1994) remains potent with observations of open dorsal notches which Janeczek et al (2008) as reported in dogs (canis familiaris) to be associated with captive breeding and domestication attempts. Variable topographic localization, number and shape of condylaris canalis ventralis observed in different subspecies of genetically related N.P. cancrivora as observed in tropical (Nigerian) subspecies do modify the location of occupant nerves and vessels thereby predisposing to neuro- vascular accidents (Bartussek, 2004; De Lahunta, 2006), possible causes of such occurrences may be due to delay in closure of anterior neuropore (Gilbert, 2006) and could be spatial or temporal (Watson et al., 1989; Gilbert, 2006). This is better studied using computed tomography (Alpak, 2003) compared to the conventional less reliable methods of analysis (Fike et al., 1984; Jurgelenas et al., 2007). This species has not been priory investigated in environmental and developmental perspectives especially in the tropics, linear cranial morphometric studies exists in Finland (Kauhala et al., 1998), Lithuania (Jurgelenas et al., 2007), Russia (Latrov, 1971), Japan (Hidaka et al., 1997), Korea (Ellerman and Morrison-Scott, 1951), Germany (Bartussek, 2005; Zevellof, 2002) and a few other European geographic locations (Ewer, 1985, Helle and Kauhala, 1991, Bartussek, 2004) on similar subject.


2 Materials and Methods

2.1 Literature review

For the purpose of the review, articles were assessed from basic searches from data base of PubMed using terms like; occipital bone, development, evolution and Nyctereutes procyonoides subspecies. The manuscripts and books consulted were from 1951 to 2015. Thus the aim of this enquiry was to review literature information on the occipital bone construction in six known and unreported subspecies of procyonoides skulls from other lands.


Fossil skulls literatures on N.p obtained from prefectures (Bjork, 1973, Hatori et al., 2003; Hohmann et al., 2001) and museums (Hidaka et al., 1997), those obtained from freshly hunted animals taken from ecologic environments (Kauhala et al., 1998; Samuel et al., 2015*) and those from Pliocene medieval periods (Hohmann et al., 2001) were variously consulted for this review.



Figure 1 Image of occipital area in Nyctereutes .procyonoides .cancrivora showing morphologic variations in condylar construction and dorsal notch in foramen magnum


3 Results

3.1 Functional morphology of the occipital bone

The occipital bone at the caudal and caudo-ventral part of the neuro-cranium is essentially, externally a joint surface area with the axial skeleton (atlanto-occipital joint) and partake in modularity of other skull parts as well for lodgments of ligamentum nuchae (pars occipitalis) on the crista nuchae externii dorsally, cleido-occipitalis sternocephalicus laterally, rectus capitis dorsalis, rectus capitis lateralis, obliquus capitis cranialis ventro-laterally (Popesco, 1977), occipito-mandibularis on the paramastoid process closely related with the supplying glossopharyngeal and hypoglossal motor nerves and the external carotid artery. The digastricus as well as occipito-hyoideus are for manipulative movements of the lower jaw (Sisson, 1975; ICVGAN, 1994) and generating characteristic bite force used in prey summarization and post-mortem processing (Ellis et al., 2009). Functional use of the head in this mesaticephalic skull for prehensile and masticatory activities varies with size and shape of the bone, as well as muscle mass attached (Dyce et al., 2002). The development of this structure is influenced by ecology and diet components in various environments as suggested by (Baltrunaite, 2005, 2006; Kauhala, 1998, Fernandes et al., 2008; Zevellof, 2002). In comparing skull dimensions in N.p. viverrinus and N.p. Usuriensis; N.p.cancrivora differs in diet typical of the cancrivorus subspecies (De La Rosa and Nocke, 2000) consisting of 40% invertebrates, 33% plant materials, 27% vertebrates (Zevellof, 2002). This carnivore-omnivore thus possesses a peculiar occipital morphology relative to similar sized carnivores (McClintock, 1981; Reid and Helgen, 2008). The glossopharyngeal, vagus, accessory, facial and mandibular nerves all contribute to the extremely fine use of the head (Ewer, 1985) in the species and has been observed to exhibit polymorphic variations in course through epigenetic and inconstantly (McClintock, 1981; De Lahunta, 1983; Gibson and Wagner, 2000) located canals and sometimes multiple foramina in the area among studied populations (Samuel et al., 2015).


3.2 Ontogenetic patterns

The cranial neural crest cells are known precursors of the mesenchyme of 3rd, 4th and 5th pharyngeal arches with early instructions on cell types to form (Noden and De Lahunta, 1985) and develop into parts of the skull whose fates are determined by Hox genes (Hoxa-3).


Allometric changes within pups, juveniles and adults age groups with reference to occipital area metric changes are presently on-going to compare different subspecies data. Correlated progression in some embryonic skull parts may have induced the phenotypic shape plasticity observed with consequences on muscle and nerve placements (Noden and De Lahunta, 1985; Gilbert, 2006) under various developmental constraints in the subspecies environments.


4 Conclusion

N.p. procyonoides, being one of the most variably sized species (McClintock, 1981; Reid and Helgen, 2008) with wide geographic radiations which have demonstrated different morphotypes in occipital area may be pre-existent mutants. Probably, the N. p. viverrinus is a more recent form than ussuriensis or procyonoides. No literary evidence to the best of our awareness is available on tropical variants of cancrivoral subspecies. We undertook this review of the specified area of the skull with a view to provide an updated appreciation of the cranial morphology of known subspecies and an awareness of developmental modeling influences which may produce morphotypes by selection predisposed by environmental stress factors and how fundamental developmental processes structure variability. The study shall also be useful in population studies, skull modeling, species anthropometry as well as solving taxonomic ambiguities in the species for conservation purposes.



Alpak H., 2003, Morphometry of the mandible of German shepherd dog (Alsatian) puppies using computed tomographic analysis. Israel Journal of Veterinary Medicine 58 (1): 15-17


Bartussek I., 2004, (in German). Die Waschbären kommen. Niedenstein, Germany: Cognitio. ISBN 978-3-932583-10-0


Baltrûnaitë L., 2005, Seasonal diet diversity of raccoon dog (Nyctereutes procyonoides Gray.) in different landscapes, Lithuania. Acta biologica universitatis Daugavpiliensis 5 (1): 75-83


Baltrûnaitë L., 2006, Diet and winter habitat use of the red fox, pine marten and raccoon dog in Dzûkija National Park, Lithuania. Acta Zoologica Lituanica 16 (1): 46-53


Bjork R. and Philip R., 1973, Transactions of the Kansas Academy of Science (1903-) Vol.76, No.1 (Spring,), pp.24-38Published by:Kansas Academy of Science Article Stable URL:


Conlon, I. and Raff M., 1999, Size control in animal development, Cell, 96(2): 235-244


De Lahunta N., 1983, Veterinary Neuroanatomy and clinical neurology, Second ed. Saunders Co. Philadelphia London


De La Rosa C. and Nocke C., 2000, A guide to the carnivores of Central America, natural history, ecology and conservation 1st edition, Universityy of Texas Press


Dyce KM, Wensing CJG, Sack WO., 2002, Textbook of Veterinary anatomy, 3rd edition, Saunders publication p 556-568


Ellis JL, Thomason J. Kebreab E. Zubair K. and France J., 2009, Cranial dimensions and forces of biting in the domestic dog J. Anat. 214, p p.362–373

PMid:19245503 PMCid:PMC2673787


Ellerman J.R. and Morrison-Scott T.C., 1951, Checklist on Palearctic and Indian mammals 1758-1946- The British museum London


Ewer RF, 1985, The carnivores -Cornel University press, Ithaca, pp.201


Fernandes M.R., Abreu A.V., Silva R.B., Silva D.F., Martinez G.L., Babinski M.A. and Ramos C.F., 2008, Maternal nutrition during lactation reduces skull growth: Experimental and morphometric investigation, Anatomical science International, 83: 123-130



Figuti E., 2004, How’s does a riverine affect the life style of a Holocene www., 2009; the occipital bone of skunk


Fike J.R., LeCouteur R.A. and Cann E.F., 1984, Anatomy of the canine orbital region. Multiplanar Imaging by CT. Veterinary Radiology 25(1): 32-36


Gibson G.and Wagner G, 2000, Canalization in evolutionary genetics: a stabilizing theory? Bioessays 22, 372–380<372::AID-BIES7>3.0.CO;2-J<372::AID-BIES7>3.3.CO;2-A


Gilbert (ed), 2006, Developmental biology, Sunderland (MA), Sinauer Associates, 6th edition pp.623-624


Hallgrimson B., C.J. Dorval M.L. Zielditch R.Z. And German, 2004, Craniofacial variability and morphological integration in mice susceptible to cleft lip and palate. J. Anat. 205, pp.501–517

PMid:15610397 PMCid:PMC1571426


Hatori K., Burdin AM., Suzuki M. and Ohtaishi N., (2003), Sex determination in Sea Otters (Enhydra lutris) J. vet. Med. Sci. 65 (4): 439-447


Helle E. and Kuahala K., 1991, Distribution history and present status of the raccoon dog in Finland, Holarctic ecology 14: 278-286


Hidaka S, Matsumoto M, Hiji H, Seiichiiroh O. and Hayao N., 1997, Morphology and morphometry of skulls of raccoon dogs Nyctereutes Procyonoides J. vet. Med. Sci. 60 (2) 161-167


Hohmann Ulf; Bartussek I. and Bernhard B., 2001, (in German). Der Waschbär. Reutlingen, Germany: Oertel+Spörer. ISBN 978-3-88627-301-0. pp.82


International Committee on Veterinary Gross Anatomical nomenclature [ICVGAN], 1994, Nomina Anatomica Veterinaria. 4th edition. Gent: World Association of Veterinary Anatomist


International Union for Conservation of Natural Resources, 2012, Red List of threatened species


Janeczek MA. Chro´szcz V. Onar GP and Pospieszny N., 2008, Morphological Analysis of the Foramen Magnum of Dogs from the Iron Age; Anat. Histol. Embryol.37, 359–361


Jurgelënas E, Daugnora L, Monastyreckienë E, and Balèiauskas L., 2007, On the skull morphology of raccoon dog (nyctereutes procyonoides) and red fox (vulpes vulpes); Acta Zoologica Lituanica, Volumen 17, Numerus 1


Kauhala KS. Viranta M. Kishimoto EH and Obara I., 1998 Skull and tooth morphology of Finnish and Japanese Raccoon dogs, Finnish zoological and botanical publishing Ann. Zool. Fennici. 35:1-16


Latrov NP., 1971, The result of introduction of the raccoon dog (Nyctereutes pocyonoides) in different provinces of the USSR- Trudy Kafedry Biologii MGZPI 29:101-166 (In Russian)


MacClintock D., 1981, A Natural History of Raccoons, Caldwell, New Jersey: The Blackburn Press. ISBN 978-1-930665-67-5

Makinen A, Kuokkanen MT. and Valtonen M., 1986, A chromosome banding study in Finnish and Japanese raccoon dogs, Hereditas, 105; 97- 105



Mayr E., 1976, Populations, Species and evolution; An abridgement of Animal species and evolution, The Belknap Press of Harvard University Press, Massachussetts


Noden DM, and De Lahunta A., 1985, The Embryology of Domestic Animals Development Mechanisms and Malformations Baltimore MD: Williams and Wilkins


Nowak E., 1984, Verbreitungs-und Bestand sentwicklung des mardahundes, Nyctereutes Procyonoides (Gray, 1834) in Europa-Zeitschrift fur jagdwissenschaft 30;137-154


Nowicki WW. Brudnicki B. and Skoczilas, 2011, Studies of interdependences between characteristics in raccoon dog (Nyctereutes procyonoides gray). Electronic Journal of Polish Agricultural universities Vol. 14:2


Popesco Peter, 1977, Atlas of Topographical Anatomy of the domestic Animals, Volume 1, 2nd edition, W. B Saunders company Philadelphia, London, Toronto


Reid F. and Helgen K. (2008) Procyon cancrivorus. In: IUCN 2012. IUCN Red List of Threatened Species, Version 2012 1 . Downloaded on 15 October 2012


Rohlf F.J., 2010, tpsDigversion 2.16 New York; Department of Ecology and Evolution,  State University of new York at StonyBrook, N.Y


Rusbridge C., and Knowler S.P., 2006, Coexistence of occipital dysplasia and occipital hypoplasia/syringomyelia in the Cavalier King Charles spaniel, J. Small Anim. Pract. 47, 603–606



Samuel OM., Olopade JO. and Onwuka, SK., 2015, Anatomical Classifications Of Accessory Symphyseal Foramina In Infants, Juveniles And Adults Raccoon (Procyonoides Nyctereutes) Mandibles. Nigerian Veterinary Journal (In Press)


Samuel, O. M., Pares-Cassanova, P.M, Olopade, J. O. Comparative Cranial Bite Force Components, Maxillo-Dental And Mandibular Morphologic Variations In Raccoon Dogs (Nyctereutes Procyonoides Spp) In Nigeria: An Index Of Fauna Quality And Diet Partitioning (Under review)


Simoens P. Poels P, and Lauwers H, 1994, Morphometric analysis of the foramen magnum in Pekingese dogs Am. J. Vet. Res.55, 34 39


Sisson S. and Grossman JD, (eds), 1975, Anatomy of Domestic animals vol 25th edition W.B Saunders company Philadelphia

Ward OG., Wurster-Hill DH., Ratty FJ., and Song Y., 1987, Comparative cytogenetics of Chinese and Japanese raccoon dogs: Nyctereutes Procyonoides, Cytogenet. Cell genet, 45: 177-186


Watson AG., de la Lahunta A. and Evans HE., 1989, Dorsal notch of the foramen magnum due to incomplete ossification of supraoccipital bone in the dogs. J. Small Anim. Pract. 30, 666–673


Zeveloff SI., 2002, Raccoons: A Natural History. Washington, D.C.: Smithsonian Books. ISBN 978-1-58834-033-7
